ITEC 2.5KVA GENERATOR – HANDLE START

ITEC Generator

Engine & Cooling – Single‑cylinder, 4‑stroke OHV engine with forced air cooling (Engine model: G200F)

Displacement – Approx. 196 cc

 Rated Output – 2.5 KVA (2 kW), with Maximum Output: ~2.8 KVA (2.5 kW)

Rated Voltage & Frequency – 230 V at 50 Hz

Ignition & Start – Recoil (handle) start; transistorized magneto ignition

Fuel Tank Capacity – ~10–15 L (most sources list 10 L)

Oil Capacity – Approx. 0.6 L

Fuel Consumption – ≤395 g/kWh

Run Time – Up to 12 hours continuous operation on a full tank

Charging Output (DC) – 12 V, 8.3 A DC port for battery charging (e.g. car, inverter)

Noise Level – ≤75 dB(A), thanks to in-built muffler and sound dissipation design

Winding – 100% copper winding for reliability and efficiency

Weight & Dimensions – Approx. 42 kg; Physical size ~590 × 475 × 460 mm

Accessories – Often includes spark plugs, oil funnel, charging cables
